INDUSTRIAL HAILSTORM DIRECT PRESSURE MEDIABLASTER

product det image
left arrow
Hailstormsandblaster Hailstormsandblaster2 Hailstormsandblaster3
right arrow

MBA |  INDUSTRIAL HAILSTORM DIRECT PRESSURE MEDIABLASTER
Part number: HailstormSandblaster

The Hailstorm model includes all the added features for operation using plastic abrasive. This machine is particularly handy for military applications which require plastic stripping when a seller forgets to add important options.

The Hailstorm Direct Pressure MediaBlaster® sandblasting cabinet is a Production capacity machine specifically designed for operation using plastic abrasive. Production machines are ideal for applications requiring one (1) hour or more of daily machine operation.

Plastic abrasive typically does not alter the surface of the substrate being processed and is available in different hardness to compensate for harder and softer parts. This is beneficial when processing parts or removing paints or powder coatings that have a chemical pretreatment underneath the topcoat you want to remain.


| Media Blast Cabinets | Sandblasting | MBA | Mediablaster | Gabinetes | Cabina | Gabinete de Sandblast | Gabinete de Arenado | Cabina para Sandblasting | Gabinete de Mesa |

Model Name:

Hailstorm

Machine Type:

Everything you need for plastic abrasive use, all included standard high duty cycle

Abrasive Delivery:

Dry, direct pressure

Air Specs:

25-90 cfm

Compressed Air Usage:

25 to 90 cfm at 80 psi

Suggested Air Compressor:

The standard nozzle size for the Hailstorm is Qwikstrip 1/4″ ID using 41 cfm at 40 psi. Smaller nozzle sizes are available for applications with smaller air compressors. Air compressors vary greatly, check the cfm output on the compressor being used or visit Air Basics for more information on compressor selection.
Pro Tip: Never buy a compressor using the displacement cfm number, always use the second cfm volume number listed with 90-100 psi inside the tank, because tank pressure reduces performance.

Recommended Abrasive Size:

Plastic Abrasive all sizes all hardness types

Additional Abrasive Info:

Machine features designed for plastic abrasive operation

Most Used Abrasive Type:

18 to 80 mesh

Dust Collector:

1100 cfm blower – 440 sq.ft. dual cartridge filters – hopper dust storage – pneumatic vibrator cleaning cycle – pneumatic conveyor – single power source electrical

Key Features:

9 production cabinets – 1.0 c.f. pot capacity – magnetic separator – anti static kit – barrel cyclone for plastic – dual filter 440 sq.ft. negative pressure dust collector – blow down controls – large ClearView window – window sweep – pneumatic conveyor with outside abrasive storage hopper – tungsten carbide nozzle

Paint Specification:

Environmentally friendly, high-grade polyurethane high gloss paint. Standard colors include MBA beige and high gloss light gray. Custom color matching is available using customer supplied color sample, please call 866-204-7068 for pricing.

STANDARD FEATURES:

  • 100% welded12- and 14-gauge CRS cabinet construction
  • Bolt-on machine hopper, replaceable
  • 1.0 cubic foot ASME coded pressure potassembly with access port
  • Pot Blow-Down controls for fast pot loading
  • Magnetic Separator
  • Anti-Static Kit
  • Stainless steel abrasive flow control valve with fine turn choke valve
  • Foot operated blast control valve with treadle pedal
  • 1/4″ Tungsten carbideQwikstrip nozzle, 70-80 mesh plastic requires nozzle reduction
  • Smaller inside ERGO flexible whip hose, replaceable
  • Advanced LED flood lighting on all models
  • Safety glass view window, 13” x 24” ClearView®
  • Glass window protector, low static
  • Window sweep to help remove static dust
  • Double panel door construction, no spills
  • Lockable refrigerator door handle
  • Safety door interlock
  • Operator Panel with Precision air-regulator, air filter/water trap with gauge
  • 10” diameter work ports with two-piece glove and gauntlet
  • Hopper Scalper Screen
  • Steel front hopper wear plate, replaceable
  • Blow-off gun
  • Dual cartridge-440 sq.ft. dust collector
  • Pneumatic vibrator cleaning cycle
  • Hopper dust storage, 3.5 cubic foot storage
  • 1100 cfm blower w/ Single Power SourceElectrical
  • Pneumatic abrasive conveyor and outside abrasive storage hopper
  • Barrel type cycloneseparator reclaimer used with plastic abrasive
  • Removable abrasive storage hopper scalper screen
  • Catalyst paint
